ROUTING TEMPLATE MFS 400

Festool MFS 400 Multi-Routing Template

At a Glance:Adjustable multi-routing template for all routers with copying ring, suitable for rectangular cut-outs from 300 x 100 mm and curved cut-outs up to Ø 600 mm.

The Festool MFS 400 is a versatile multi-routing template designed for precise routing work with routers fitted with a copying ring. It can be adjusted quickly and accurately for different routing tasks, making it ideal for rectangular cut-outs, curved cut-outs, circles, recesses, profiles and repeatable template work. With millimetre-accurate scales, integrated clamping grooves and included angle stops, the MFS 400 helps deliver neat, controlled and professional routing results in workshop, cabinetry, joinery and installation applications.

The adjustable routing template with all the options

The MFS 400 gives users a stable and accurate template system for routing cut-outs and curves. It can be fixed securely to the workpiece using suitable screw clamps or lever clamps, while the included circle routing insert makes it especially useful for safe and controlled circular routing work.

Product highlights

• For routers with copying ring: Suitable for all routers fitted with the correct copying ring setup.
• Adjustable template system: Profiles can be set quickly and precisely for a wide range of routing tasks.
• Millimetre-accurate scale: Scales on the profiles help improve accuracy when making cut-outs and curves.
• Integrated clamping groove: Allows the template to be secured to the workpiece with suitable screw clamps or lever clamps.
• Angle stops included: Helps align the template accurately with the workpiece.
• Circle routing insert included: Allows safer and more controlled routing of circles and curves.
• Expandable system: Can be extended systematically with compatible table/profile extensions from 200 mm to 2000 mm.
• Flexible routing range: Suitable for rectangular cut-outs from 300 x 100 mm and curved cut-outs up to Ø 600 mm.
